Iconic Style with Integrated Access
The Summit Express TR offers a striking triple-function design: ladder access, an exhilarating high-velocity slide, and wide mesh splash zones at the base. Its architectural presence commands attention on the water, while its compact footprint makes it easier to integrate than taller features.
Designed with Aquaglide's TR (Trickler Ready) system, operators can enhance the sliding experience with optional irrigation, keeping surfaces safe and slippery in the summer sun.
Note: Escalade Summit Climbing Wall & Summit Express Trickler Hose Kit sold separately.
[CA] PROP 65 WARNING: This product can expose you to DEHP, a chemical known to the State of California to cause Cancer, birth defects, or other reproductive harm. For more info go to www.P65Warnings.ca.gov.
Features
- Best For: Sliding, playing, bouncing, hanging, and relaxing.
- Capacity: 12 Adults / 12 Children
- Warranty: 3-year limited against any manufacturing defects.
- Dimensions: 29’10” L (909 cm) x 9’ W (274 cm) x 16’5” H (500 cm)
- Slide Height: 12’2” (3,71m)
- Box Dimensions: L 52″ x W 43″ x H 34.2″ (L 132cm x W 110cm x H 87cm)
- Min Water Depth: 11’ (3.3 m)
- Includes: Summit Express and repair kit.
- Not Included: Trickler Hose Kit, boarding platform, anchor weights, mooring lines, Vario-Lock™ straps, and inflation pump.
Key Tech Features
- Double I-Beam – Extra-reinforced, welded double-I-Beam construction with 3-layer seams.
- Tubular – Integrates welded structural tube construction with 3-layer seams.
- Duratex Cx3 – Premium commercial-grade material optimized for durability, weld strength and UV resistance in our signature items.
- Tritex Cx3– Uniquely textured version of our Duratex material adding grip and cooling attributes.
- Interlock 5 – 3 sets of secure and tamper-free 5-ring connections using our 2-Step Vario Strap system.
- Halkey-Roberts valves – With tamper-proof cap for quick, effective inflation/ deflation.
- PRV – Pressure relief valve to help protect against catastrophic over-inflation.
Key User Activities
- Trickler Ready – Built-in pockets and attachments for optional slide-face irrigation system.
- Climb – Integrated novice, stepped climbing line.
- Slide – Features an exciting zero entry slide feature for ultimate enjoyment.
- Cave – Adds interest with a shaded cave feature.
- Multi-level – Diverse multi-level play area accommodates more users.
- Monkey – Features overhead grip or monkey bar style handles which add to the fun!
Technical Specifications
- Material – 0.90 mm / 31 oz Cx3
- Max Weight – 2,500 lb. (1,134 kg) max weight.
- Minimum Distance from Shore – 15’ (4.5 m)
- Minimum Required Total Anchor Weight – 6,600 lb. (3,000 kg)
- Anchor Rings: – 6
- Accessory Attachment D-rings – 5 each on 3 sides.
Product Notes
- Trickler Hose Kit sold seperately.
- Weight recommendations are for anchoring in conditions with extreme weather, waves, or other abnormal conditions. Aquaglide recommends contacting a dock and mooring specialist for anchor installation options and assistance.
- If utilizing as a standalone piece, this item requires a boarding platform (not included) such as Swimstep XL, Swimstep 5×5, Speedway 10, Speedway 20, or Splashmat.
- The safety of our customers and their guests is our highest priority. Careful thought goes into the design of our aquapark components, connection points and configurations to assure maximum safety and enjoyment. Consequently, Aquaglide Lakefront and Aquapark products are not authorized for use in combination with products or attachments from any other manufacturer. Aquaglide product combinations must be authorized or approved in advance by the manufacturer. Use of Aquaglide products in combination with products from any other manufacturer and/or product arrangements not previously approved by Aquaglide may result in increased risk of entrapment, injury, or death.
