Choose Your Path. Master the Flow.
The Hatchway 20 is an obstacle with options—crawl through, hurdle over, or tiptoe around. With multiple routes to navigate, it challenges both speed and strategy. Nimble users may race straight through the center, while more cautious guests work the edges, making it a dynamic and inclusive feature for a range of ages and abilities.
Ideal for maintaining momentum in a track run, Hatchway 20 connects on all four sides using the D-Ring Interloc system, adding energy and versatility to any aquapark layout.
[CA] PROP 65 WARNING: This product can expose you to DEHP, a chemical known to the State of California to cause Cancer, birth defects, or other reproductive harm. For more info go to www.P65Warnings.ca.gov.
Features
- Best For: Sliding or balance obstacle challenge in a 20-foot format.
- Capacity: 4 Adults / 4 Children
- Warranty: 3-year limited against any manufacturing defects.
- Dimensions: 20’-0” L (610 cm) x 6’-6” W (198 cm) x 5’-7” H (170 cm).
- Min Water Depth: 5’ 8 (1.75 m)
- Not Included: Anchor weights, mooring lines, Vario-Lock™ straps, and inflation pump.
Key Tech Features
- Double I-Beam – Extra-reinforced, welded double-I-Beam construction with 3-layer seams.
- Duratex Cx3 – Premium commercial-grade material optimized for durability, weld strength and UV resistance in our signature items.
- Interlock 5 – 4 sets of secure and tamper-free 5-ring connections using our 2-Step Vario Strap system.
- Halkey-Roberts valves – With tamper-proof cap for quick, effective inflation/ deflation.
- PRV – Pressure relief valve to help protect against catastrophic over-inflation.
Key User Activities
- Obstacle – The Hatchway itself presents an obstacle challenge with multiple solutions: over, around or through!
- Slide – Part of the challenge and part of the fun. Integrates a unique sliding entry/ exit feature for maximum fun.
- Balance – Offers a challenging balance element to keep users on their toes.
Technical Specifications
- Max Weight: 800 lb. (363 kg) max weight.
- Capacity: 4 Adults / 4 Children
- Weight: 178.1 lb. (80.8 kg)
- Material: 0.90 mm / 31 oz Cx3
- Dimensions: 20’-0” L (610 cm) x 6’-6” W (198 cm) x 5’-7” H (170 cm).
- Minimum Required Water Depth: 5’ 8 (1.75 m)
- Minimum Distance from Shore: 10’ (3.0 m)
- Minimum Required Total Anchor Weight: 4,400 lb. (2,000 kg)
- Anchor Rings: 4
- Accessory Attachment D-rings: 5 each on 4 sides.
Product Notes
- Weight recommendations are for anchoring in conditions with extreme weather, waves, or other abnormal conditions. Aquaglide recommends contacting a dock and mooring specialist for anchor installation options and assistance.
- The safety of our customers and their guests is our highest priority. Careful thought goes into the design of our aquapark components, connection points and configurations to assure maximum safety and enjoyment. Consequently, Aquaglide Lakefront and Aquapark products are not authorized for use in combination with products or attachments from any other manufacturer. Aquaglide product combinations must be authorized or approved in advance by the manufacturer. Use of Aquaglide products in combination with products from any other manufacturer and/or product arrangements not previously approved by Aquaglide may result in increased risk of entrapment, injury, or death.
